[Maximum inrush current]: 49A [Input voltage]: 3.3-5VDC [Maximum switching frequency]: 2000 times/second 12-24VDC [PWM maximum frequency]: 500 times/sec [Output voltage]: 12-24VDC [Isolation method]: Opto-decoupling isolation
[Input level]: NPN/PNP universal [Isolation voltage]: 3000V [Output Level]: Low/NPN [Flame resistance level]: UL94V_0 [Input point trigger current]: 5-12mA [Response speed]: 0.5ms [Output point rated current]: 3A for a long time [Drive Component]: MOSFET
[Maximum current at output point]: 5A for a short time [Energized light on]: Each output channel has an LED light [Output Type]: Non-contact type [Short Circuit Protection]; Auto-shutdown, auto-recovery
[Total current per group]: 16A [Relay Protection]: The tube has a belt [Surge voltage]: 60V [Mounting method] :D IN rail mounting [Switch life] unlimited times [Operating temperature]: -40+60°C
(welded behind the board) Short-circuit protection: automatic relay opening Automatic recovery effectively protects components from burning out) Opto-coupling isolation (Anti-interference noise) Relay protection (Strong protection performance) High-quality flame retardant housing LED indicator (Indicator light for each output channel)
